Copy turning cutter PL type P47

COATED

Ordering by Catalog

Copy turning cutter PL type P47

Catalog Order List

Execution
- Left
- Right

Search Start search

	Filter
	Filter
Order Designation	Stock	a	dh6	Dmin	f	L	L1	R	tmax	CAD Data	Selection
LP47.4-20/P04Cleft, cm-1, a-3-5, dh6-4, Dmin-4, f-1-5, L-34, L1-20, R-0-1, tmax-0-3,	approx. 4 working days	3.5	4	4	1.5	34	20	0.1	0.3		To order
LP47.5-25/P04Cleft, cm-1, a-4-4, dh6-5, Dmin-5, f-1-9, L-40, L1-25, R-0-15, tmax-0-5,	approx. 4 working days	4.4	5	5	1.9	40	25	0.15	0.5		To order
LP47.6-30/P04Cleft, cm-1, a-5-3, dh6-6, Dmin-6, f-2-3, L-45, L1-30, R-0-15, tmax-0-5,	approx. 4 working days	5.3	6	6	2.3	45	30	0.15	0.5		To order
LP47T2-10/P04Cleft, cm-1, a-1-7, dh6-4, Dmin-2, L-24, L1-10, R-0-05, tmax-0-4,	approx. 4 working days	1.7	4	2		24	10	0.05	0.4		To order
LP47T3-15/P04Cleft, cm-1, a-2-6, dh6-4, Dmin-2-8, f-0-6, L-29, L1-15, R-0-1, tmax-0-6,	approx. 4 working days	2.6	4	2.8	0.6	29	15	0.1	0.6		To order
LP47T4-10/P04Cleft, cm-1, a-3-5, dh6-4, Dmin-4, f-1-5, L-24, L1-10, R-0-1, tmax-0-6,	approx. 4 working days	3.5	4	4	1.5	24	10	0.1	0.6		To order
LP47T4-20/P04Cleft, cm-1, a-3-5, dh6-4, Dmin-4, f-1-5, L-34, L1-20, R-0-1, tmax-0-6,	approx. 4 working days	3.5	4	4	1.5	34	20	0.1	0.6		To order
LP47T5-15/P04Cleft, cm-1, a-4-4, dh6-5, Dmin-5, f-1-9, L-30, L1-15, R-0-15, tmax-0-8,	approx. 4 working days	4.4	5	5	1.9	30	15	0.15	0.8		To order
LP47T5-25/P04Cleft, cm-1, a-4-4, dh6-5, Dmin-5, f-1-9, L-40, L1-25, R-0-15, tmax-0-8,	approx. 4 working days	4.4	5	5	1.9	40	25	0.15	0.8		To order
LP47T6-22/P04Cleft, cm-1, a-5-3, dh6-6, Dmin-6, f-2-3, L-37, L1-22, R-0-15, tmax-1-8,	approx. 4 working days	5.3	6	6	2.3	37	22	0.15	1.8		To order
LP47T6-30/P04Cleft, cm-1, a-5-3, dh6-6, Dmin-6, f-2-3, L-45, L1-30, R-0-15, tmax-1-8,	approx. 4 working days	5.3	6	6	2.3	45	30	0.15	1.8		To order
RP47.4-20/P04Cright, cm-1, a-3-5, dh6-4, Dmin-4, f-1-5, L-34, L1-20, R-0-1, tmax-0-3,	approx. 4 working days	3.5	4	4	1.5	34	20	0.1	0.3		To order
RP47.5-25/P04Cright, cm-1, a-4-4, dh6-5, Dmin-5, f-1-9, L-40, L1-25, R-0-15, tmax-0-5,	approx. 4 working days	4.4	5	5	1.9	40	25	0.15	0.5		To order
RP47.6-30/P04Cright, cm-1, a-5-3, dh6-6, Dmin-6, f-2-3, L-45, L1-30, R-0-15, tmax-0-5,	approx. 4 working days	5.3	6	6	2.3	45	30	0.15	0.5		To order
RP47T2-10/P04Cright, cm-1, a-1-7, dh6-4, Dmin-2, L-24, L1-10, R-0-05, tmax-0-4,	approx. 12 working days	1.7	4	2		24	10	0.05	0.4		To order
RP47T3-15/P04Cright, cm-1, a-2-6, dh6-4, Dmin-2-8, f-0-6, L-29, L1-15, R-0-1, tmax-0-6,	approx. 4 working days	2.6	4	2.8	0.6	29	15	0.1	0.6		To order
RP47T4-10/P04Cright, cm-1, a-3-5, dh6-4, Dmin-4, f-1-5, L-24, L1-10, R-0-1, tmax-0-6,	approx. 4 working days	3.5	4	4	1.5	24	10	0.1	0.6		To order
RP47T4-20/P04Cright, cm-1, a-3-5, dh6-4, Dmin-4, f-1-5, L-34, L1-20, R-0-1, tmax-0-6,	approx. 4 working days	3.5	4	4	1.5	34	20	0.1	0.6		To order
RP47T5-15/P04Cright, cm-1, a-4-4, dh6-5, Dmin-5, f-1-9, L-30, L1-15, R-0-15, tmax-0-8,	approx. 4 working days	4.4	5	5	1.9	30	15	0.15	0.8		To order
RP47T5-25/P04Cright, cm-1, a-4-4, dh6-5, Dmin-5, f-1-9, L-40, L1-25, R-0-15, tmax-0-8,	approx. 4 working days	4.4	5	5	1.9	40	25	0.15	0.8		To order
RP47T6-22/P04Cright, cm-1, a-5-3, dh6-6, Dmin-6, f-2-3, L-37, L1-22, R-0-15, tmax-1-8,	approx. 4 working days	5.3	6	6	2.3	37	22	0.15	1.8		To order
RP47T6-30/P04Cright, cm-1, a-5-3, dh6-6, Dmin-6, f-2-3, L-45, L1-30, R-0-15, tmax-1-8,	approx. 4 working days	5.3	6	6	2.3	45	30	0.15	1.8		To order
