Face grooving insert type 020

COATED

Ordering by Catalog

Face grooving insert type 020

Catalog Order List

Execution
- Left
- Right
Grade

Search Start search

	Filter
	Filter
Order Designation	Stock	a	b (+0.05)	dh6	Dmin	L	R	tmax	CAD Data	Selection
L020.0300-25 AL41Fleft, cm-1, a-5-5, b (+0.05)-3, dh6-8, Dmin-20, L-45, R-0-2, tmax-25,	approx. 4 working days	5.5	3	8	20	45	0.2	25		To order
L020.0300-25 PD2Fleft, cm-2, a-5-5, b (+0.05)-3, dh6-8, Dmin-20, L-45, R-0-2, tmax-25,	approx. 4 working days	5.5	3	8	20	45	0.2	25		To order
L020.0300-30 AL41Fleft, cm-1, a-5-5, b (+0.05)-3, dh6-8, Dmin-20, L-50, R-0-2, tmax-30,	approx. 4 working days	5.5	3	8	20	50	0.2	30		To order
L020.0300-30 PD2Fleft, cm-2, a-5-5, b (+0.05)-3, dh6-8, Dmin-20, L-50, R-0-2, tmax-30,	approx. 4 working days	5.5	3	8	20	50	0.2	30		To order
L020.0300-35 AL41Fleft, cm-1, a-5-5, b (+0.05)-3, dh6-8, Dmin-20, L-55, R-0-2, tmax-35,	approx. 4 working days	5.5	3	8	20	55	0.2	35		To order
L020.0300-35 PD2Fleft, cm-2, a-5-5, b (+0.05)-3, dh6-8, Dmin-20, L-55, R-0-2, tmax-35,	approx. 4 working days	5.5	3	8	20	55	0.2	35		To order
L020.0300-40 AL41Fleft, cm-1, a-5-5, b (+0.05)-3, dh6-8, Dmin-20, L-60, R-0-2, tmax-40,	approx. 4 working days	5.5	3	8	20	60	0.2	40		To order
L020.0300-40 PD2Fleft, cm-2, a-5-5, b (+0.05)-3, dh6-8, Dmin-20, L-60, R-0-2, tmax-40,	approx. 4 working days	5.5	3	8	20	60	0.2	40		To order
L020.0400-25 AL41Fleft, cm-1, a-6, b (+0.05)-4, dh6-8, Dmin-20, L-45, R-0-2, tmax-25,	approx. 4 working days	6	4	8	20	45	0.2	25		To order
L020.0400-25 PD2Fleft, cm-2, a-6, b (+0.05)-4, dh6-8, Dmin-20, L-45, R-0-2, tmax-25,	approx. 4 working days	6	4	8	20	45	0.2	25		To order
L020.0400-30 AL41Fleft, cm-1, a-6, b (+0.05)-4, dh6-8, Dmin-20, L-50, R-0-2, tmax-30,	approx. 4 working days	6	4	8	20	50	0.2	30		To order
L020.0400-30 PD2Fleft, cm-2, a-6, b (+0.05)-4, dh6-8, Dmin-20, L-50, R-0-2, tmax-30,	approx. 4 working days	6	4	8	20	50	0.2	30		To order
L020.0400-35 AL41Fleft, cm-1, a-6, b (+0.05)-4, dh6-8, Dmin-20, L-55, R-0-2, tmax-35,	approx. 4 working days	6	4	8	20	55	0.2	35		To order
L020.0400-35 PD2Fleft, cm-2, a-6, b (+0.05)-4, dh6-8, Dmin-20, L-55, R-0-2, tmax-35,	approx. 4 working days	6	4	8	20	55	0.2	35		To order
L020.0400-40 AL41Fleft, cm-1, a-6, b (+0.05)-4, dh6-8, Dmin-20, L-60, R-0-2, tmax-40,	approx. 4 working days	6	4	8	20	60	0.2	40		To order
L020.0400-40 PD2Fleft, cm-2, a-6, b (+0.05)-4, dh6-8, Dmin-20, L-60, R-0-2, tmax-40,	approx. 4 working days	6	4	8	20	60	0.2	40		To order
L020.0500-20 AL41Fleft, cm-1, a-6-5, b (+0.05)-5, dh6-8, Dmin-20, L-40, R-0-2, tmax-20,	approx. 4 working days	6.5	5	8	20	40	0.2	20		To order
L020.0500-20 PD2Fleft, cm-2, a-6-5, b (+0.05)-5, dh6-8, Dmin-20, L-40, R-0-2, tmax-20,	approx. 4 working days	6.5	5	8	20	40	0.2	20		To order
L020.0500-25 AL41Fleft, cm-1, a-6-5, b (+0.05)-5, dh6-8, Dmin-20, L-45, R-0-2, tmax-25,	approx. 4 working days	6.5	5	8	20	45	0.2	25		To order
L020.0500-25 PD2Fleft, cm-2, a-6-5, b (+0.05)-5, dh6-8, Dmin-20, L-45, R-0-2, tmax-25,	approx. 4 working days	6.5	5	8	20	45	0.2	25		To order
L020.0500-30 AL41Fleft, cm-1, a-6-5, b (+0.05)-5, dh6-8, Dmin-20, L-50, R-0-2, tmax-30,	approx. 4 working days	6.5	5	8	20	50	0.2	30		To order
L020.0500-30 PD2Fleft, cm-2, a-6-5, b (+0.05)-5, dh6-8, Dmin-20, L-50, R-0-2, tmax-30,	approx. 4 working days	6.5	5	8	20	50	0.2	30		To order
L020.0500-35 AL41Fleft, cm-1, a-6-5, b (+0.05)-5, dh6-8, Dmin-20, L-55, R-0-2, tmax-35,	approx. 4 working days	6.5	5	8	20	55	0.2	35		To order
L020.0500-35 PD2Fleft, cm-2, a-6-5, b (+0.05)-5, dh6-8, Dmin-20, L-55, R-0-2, tmax-35,	approx. 4 working days	6.5	5	8	20	55	0.2	35		To order
L020.0500-40 AL41Fleft, cm-1, a-6-5, b (+0.05)-5, dh6-8, Dmin-20, L-60, R-0-2, tmax-40,	approx. 4 working days	6.5	5	8	20	60	0.2	40		To order
L020.0500-40 PD2Fleft, cm-2, a-6-5, b (+0.05)-5, dh6-8, Dmin-20, L-60, R-0-2, tmax-40,	approx. 4 working days	6.5	5	8	20	60	0.2	40		To order
R020.0300-25 AL41Fright, cm-1, a-5-5, b (+0.05)-3, dh6-8, Dmin-20, L-45, R-0-2, tmax-25,	2 pieces	5.5	3	8	20	45	0.2	25		To order
R020.0300-25 PD2Fright, cm-2, a-5-5, b (+0.05)-3, dh6-8, Dmin-20, L-45, R-0-2, tmax-25,	approx. 3 working days	5.5	3	8	20	45	0.2	25		To order
R020.0300-30 AL41Fright, cm-1, a-5-5, b (+0.05)-3, dh6-8, Dmin-20, L-50, R-0-2, tmax-30,	5 pieces	5.5	3	8	20	50	0.2	30		To order
R020.0300-30 PD2Fright, cm-2, a-5-5, b (+0.05)-3, dh6-8, Dmin-20, L-50, R-0-2, tmax-30,	approx. 4 working days	5.5	3	8	20	50	0.2	30		To order
R020.0300-35 AL41Fright, cm-1, a-5-5, b (+0.05)-3, dh6-8, Dmin-20, L-55, R-0-2, tmax-35,	approx. 4 working days	5.5	3	8	20	55	0.2	35		To order
R020.0300-35 PD2Fright, cm-2, a-5-5, b (+0.05)-3, dh6-8, Dmin-20, L-55, R-0-2, tmax-35,	approx. 4 working days	5.5	3	8	20	55	0.2	35		To order
R020.0300-40 AL41Fright, cm-1, a-5-5, b (+0.05)-3, dh6-8, Dmin-20, L-60, R-0-2, tmax-40,	approx. 4 working days	5.5	3	8	20	60	0.2	40		To order
R020.0300-40 PD2Fright, cm-2, a-5-5, b (+0.05)-3, dh6-8, Dmin-20, L-60, R-0-2, tmax-40,	approx. 4 working days	5.5	3	8	20	60	0.2	40		To order
R020.0400-25 AL41Fright, cm-1, a-6, b (+0.05)-4, dh6-8, Dmin-20, L-45, R-0-2, tmax-25,	2 pieces	6	4	8	20	45	0.2	25		To order
R020.0400-25 PD2Fright, cm-2, a-6, b (+0.05)-4, dh6-8, Dmin-20, L-45, R-0-2, tmax-25,	3 pieces	6	4	8	20	45	0.2	25		To order
R020.0400-30 AL41Fright, cm-1, a-6, b (+0.05)-4, dh6-8, Dmin-20, L-50, R-0-2, tmax-30,	approx. 4 working days	6	4	8	20	50	0.2	30		To order
R020.0400-30 PD2Fright, cm-2, a-6, b (+0.05)-4, dh6-8, Dmin-20, L-50, R-0-2, tmax-30,	approx. 4 working days	6	4	8	20	50	0.2	30		To order
R020.0400-35 AL41Fright, cm-1, a-6, b (+0.05)-4, dh6-8, Dmin-20, L-55, R-0-2, tmax-35,	approx. 4 working days	6	4	8	20	55	0.2	35		To order
R020.0400-35 PD2Fright, cm-2, a-6, b (+0.05)-4, dh6-8, Dmin-20, L-55, R-0-2, tmax-35,	approx. 4 working days	6	4	8	20	55	0.2	35		To order
R020.0400-40 AL41Fright, cm-1, a-6, b (+0.05)-4, dh6-8, Dmin-20, L-60, R-0-2, tmax-40,	approx. 2 working days	6	4	8	20	60	0.2	40		To order
R020.0400-40 PD2Fright, cm-2, a-6, b (+0.05)-4, dh6-8, Dmin-20, L-60, R-0-2, tmax-40,	approx. 4 working days	6	4	8	20	60	0.2	40		To order
R020.0500-20 AL41Fright, cm-1, a-6-5, b (+0.05)-5, dh6-8, Dmin-20, L-40, R-0-2, tmax-20,	approx. 4 working days	6.5	5	8	20	40	0.2	20		To order
R020.0500-20 PD2Fright, cm-2, a-6-5, b (+0.05)-5, dh6-8, Dmin-20, L-40, R-0-2, tmax-20,	approx. 4 working days	6.5	5	8	20	40	0.2	20		To order
R020.0500-25 AL41Fright, cm-1, a-6-5, b (+0.05)-5, dh6-8, Dmin-20, L-45, R-0-2, tmax-25,	approx. 4 working days	6.5	5	8	20	45	0.2	25		To order
R020.0500-25 PD2Fright, cm-2, a-6-5, b (+0.05)-5, dh6-8, Dmin-20, L-45, R-0-2, tmax-25,	approx. 4 working days	6.5	5	8	20	45	0.2	25		To order
R020.0500-30 AL41Fright, cm-1, a-6-5, b (+0.05)-5, dh6-8, Dmin-20, L-50, R-0-2, tmax-30,	approx. 2 working days	6.5	5	8	20	50	0.2	30		To order
R020.0500-30 PD2Fright, cm-2, a-6-5, b (+0.05)-5, dh6-8, Dmin-20, L-50, R-0-2, tmax-30,	approx. 4 working days	6.5	5	8	20	50	0.2	30		To order
R020.0500-35 AL41Fright, cm-1, a-6-5, b (+0.05)-5, dh6-8, Dmin-20, L-55, R-0-2, tmax-35,	approx. 3 working days	6.5	5	8	20	55	0.2	35		To order
R020.0500-35 PD2Fright, cm-2, a-6-5, b (+0.05)-5, dh6-8, Dmin-20, L-55, R-0-2, tmax-35,	approx. 4 working days	6.5	5	8	20	55	0.2	35		To order
R020.0500-40 AL41Fright, cm-1, a-6-5, b (+0.05)-5, dh6-8, Dmin-20, L-60, R-0-2, tmax-40,	approx. 2 working days	6.5	5	8	20	60	0.2	40		To order
R020.0500-40 PD2Fright, cm-2, a-6-5, b (+0.05)-5, dh6-8, Dmin-20, L-60, R-0-2, tmax-40,	approx. 4 working days	6.5	5	8	20	60	0.2	40		To order
