Grooving cutter type 006

COATED

Ordering by Catalog

Grooving cutter type 006

Catalog Order List

Execution
- Left
- Right
Grade

Search Start search

	Filter
	Filter
Order Designation	Stock	a	b (+0.05)	dh6	Dmin	f	L	L1	tmax	CAD Data	Selection
L.006.0100-10 AL41F, cm-1, a-5-3, b (+0.05)-1, dh6-6, Dmin-6, f-2-3, L-25, L1-10, tmax-1-8,	approx. 4 working days	5.3	1	6	6	2.3	25	10	1.8		To order
L.006.0100-10 CN45Fleft, cm-2, a-5-3, b (+0.05)-1, dh6-6, Dmin-6, f-2-3, L-25, L1-10, tmax-1-8,	approx. 4 working days	5.3	1	6	6	2.3	25	10	1.8		To order
L.006.0100-15 AL41F, cm-1, a-5-3, b (+0.05)-1, dh6-6, Dmin-6, f-2-3, L-30, L1-15, tmax-1-8,	approx. 4 working days	5.3	1	6	6	2.3	30	15	1.8		To order
L.006.0100-15 CN45Fleft, cm-2, a-5-3, b (+0.05)-1, dh6-6, Dmin-6, f-2-3, L-30, L1-15, tmax-1-8,	approx. 4 working days	5.3	1	6	6	2.3	30	15	1.8		To order
L.006.0100-22 CN45Fleft, cm-2, a-5-3, b (+0.05)-1, dh6-6, Dmin-6, f-2-3, L-37, L1-22, tmax-1-8,	approx. 4 working days	5.3	1	6	6	2.3	37	22	1.8		To order
L.006.0100-25 AL41F, cm-1, a-5-3, b (+0.05)-1, dh6-6, Dmin-6, f-2-3, L-40, L1-25, tmax-1-8,	about 2 weeks	5.3	1	6	6	2.3	40	25	1.8		To order
L.006.0100-25 CN45Fleft, cm-2, a-5-3, b (+0.05)-1, dh6-6, Dmin-6, f-2-3, L-40, L1-25, tmax-1-8,	approx. 4 working days	5.3	1	6	6	2.3	40	25	1.8		To order
L.006.0100-30 AL41F, cm-1, a-5-3, b (+0.05)-1, dh6-6, Dmin-6, f-2-3, L-45, L1-30, tmax-1-8,	about 2 weeks	5.3	1	6	6	2.3	45	30	1.8		To order
L.006.0100-30 CN45Fleft, cm-2, a-5-3, b (+0.05)-1, dh6-6, Dmin-6, f-2-3, L-45, L1-30, tmax-1-8,	approx. 4 working days	5.3	1	6	6	2.3	45	30	1.8		To order
L.006.0100-35 AL41F, cm-1, a-5-3, b (+0.05)-1, dh6-6, Dmin-6, f-2-3, L-50, L1-35, tmax-1-8,	about 2 weeks	5.3	1	6	6	2.3	50	35	1.8		To order
L.006.0100-35 CN45Fleft, cm-2, a-5-3, b (+0.05)-1, dh6-6, Dmin-6, f-2-3, L-50, L1-35, tmax-1-8,	approx. 4 working days	5.3	1	6	6	2.3	50	35	1.8		To order
L.006.0100-35 K10Fleft, cm-1, a-5-3, b (+0.05)-1, dh6-6, Dmin-6, f-2-3, L-50, L1-35, tmax-1-8,	approx. 4 working days	5.3	1	6	6	2.3	50	35	1.8		To order
L.006.0100-42 CN45Fleft, cm-2, a-5-3, b (+0.05)-1, dh6-6, Dmin-6, f-2-3, L-57, L1-42, tmax-1-8,	approx. 4 working days	5.3	1	6	6	2.3	57	42	1.8		To order
L.006.0150-10 CN45Fleft, cm-2, a-5-3, b (+0.05)-1-5, dh6-6, Dmin-6, f-2-3, L-25, L1-10, tmax-1-8,	approx. 4 working days	5.3	1.5	6	6	2.3	25	10	1.8		To order
L.006.0150-15 AL41F, cm-1, a-5-3, b (+0.05)-1-5, dh6-6, Dmin-6, f-2-3, L-30, L1-15, tmax-1-8,	about 2 weeks	5.3	1.5	6	6	2.3	30	15	1.8		To order
L.006.0150-15 CN45Fleft, cm-2, a-5-3, b (+0.05)-1-5, dh6-6, Dmin-6, f-2-3, L-30, L1-15, tmax-1-8,	approx. 4 working days	5.3	1.5	6	6	2.3	30	15	1.8		To order
L.006.0150-22 CN45Fleft, cm-2, a-5-3, b (+0.05)-1-5, dh6-6, Dmin-6, f-2-3, L-37, L1-22, tmax-1-8,	approx. 4 working days	5.3	1.5	6	6	2.3	37	22	1.8		To order
L.006.0150-25 AL41F, cm-1, a-5-3, b (+0.05)-1-5, dh6-6, Dmin-6, f-2-3, L-40, L1-25, tmax-1-8,	approx. 4 working days	5.3	1.5	6	6	2.3	40	25	1.8		To order
L.006.0150-25 CN45Fleft, cm-2, a-5-3, b (+0.05)-1-5, dh6-6, Dmin-6, f-2-3, L-40, L1-25, tmax-1-8,	approx. 4 working days	5.3	1.5	6	6	2.3	40	25	1.8		To order
L.006.0150-30 CN45Fleft, cm-2, a-5-3, b (+0.05)-1-5, dh6-6, Dmin-6, f-2-3, L-45, L1-30, tmax-1-8,	approx. 4 working days	5.3	1.5	6	6	2.3	45	30	1.8		To order
L.006.0150-35 AL41F, cm-1, a-5-3, b (+0.05)-1-5, dh6-6, Dmin-6, f-2-3, L-50, L1-35, tmax-1-8,	approx. 4 working days	5.3	1.5	6	6	2.3	50	35	1.8		To order
L.006.0150-35 CN45Fleft, cm-2, a-5-3, b (+0.05)-1-5, dh6-6, Dmin-6, f-2-3, L-50, L1-35, tmax-1-8,	approx. 4 working days	5.3	1.5	6	6	2.3	50	35	1.8		To order
L.006.0150-35 K10Fleft, cm-1, a-5-3, b (+0.05)-1-5, dh6-6, Dmin-6, f-2-3, L-50, L1-35, tmax-1-8,	approx. 4 working days	5.3	1.5	6	6	2.3	50	35	1.8		To order
L.006.0200-10 AL41F, cm-1, a-5-3, b (+0.05)-2, dh6-6, Dmin-6, f-2-3, L-25, L1-10, tmax-1-8,	approx. 4 working days	5.3	2	6	6	2.3	25	10	1.8		To order
L.006.0200-10 CN45Fleft, cm-2, a-5-3, b (+0.05)-3, dh6-6, Dmin-6, f-2-3, L-25, L1-10, tmax-1-8,	approx. 4 working days	5.3	3	6	6	2.3	25	10	1.8		To order
L.006.0200-15 AL41Fleft, cm-3, a-5-3, b (+0.05)-5, dh6-6, Dmin-6, f-2-3, L-30, L1-15, tmax-1-8,	approx. 4 working days	5.3	5	6	6	2.3	30	15	1.8		To order
L.006.0200-15 CN45Fleft, cm-2, a-5-3, b (+0.05)-6, dh6-6, Dmin-6, f-2-3, L-30, L1-15, tmax-1-8,	approx. 4 working days	5.3	6	6	6	2.3	30	15	1.8		To order
L.006.0200-22 AL41F, cm-1, a-5-3, b (+0.05)-8, dh6-6, Dmin-6, f-2-3, L-37, L1-22, tmax-1-8,	approx. 4 working days	5.3	8	6	6	2.3	37	22	1.8		To order
L.006.0200-22 CN45Fleft, cm-2, a-5-3, b (+0.05)-9, dh6-6, Dmin-6, f-2-3, L-37, L1-22, tmax-1-8,	approx. 4 working days	5.3	9	6	6	2.3	37	22	1.8		To order
L.006.0200-25 AL41F, cm-1, a-5-3, b (+0.05)-11, dh6-6, Dmin-6, f-2-3, L-40, L1-25, tmax-1-8,	approx. 4 working days	5.3	11	6	6	2.3	40	25	1.8		To order
L.006.0200-25 CN45Fleft, cm-2, a-5-3, b (+0.05)-12, dh6-6, Dmin-6, f-2-3, L-40, L1-25, tmax-1-8,	approx. 4 working days	5.3	12	6	6	2.3	40	25	1.8		To order
L.006.0200-30 AL41F, cm-1, a-5-3, b (+0.05)-14, dh6-6, Dmin-6, f-2-3, L-45, L1-30, tmax-1-8,	approx. 4 working days	5.3	14	6	6	2.3	45	30	1.8		To order
L.006.0200-30 CN45Fleft, cm-2, a-5-3, b (+0.05)-15, dh6-6, Dmin-6, f-2-3, L-45, L1-30, tmax-1-8,	approx. 4 working days	5.3	15	6	6	2.3	45	30	1.8		To order
L006.0150-10 AL41Fleft, cm-3, a-5-3, b (+0.05)-1-5, dh6-6, Dmin-6, f-2-3, L-25, L1-10, tmax-1-8,	approx. 4 working days	5.3	1.5	6	6	2.3	25	10	1.8		To order
L006.0150-22 AL41F, cm-1, a-5-3, b (+0.05)-1-5, dh6-6, Dmin-6, f-2-3, L-37, L1-22, tmax-1-8,	approx. 4 working days	5.3	1.5	6	6	2.3	37	22	1.8		To order
L006.0150-30 AL41F, cm-1, a-5-3, b (+0.05)-1-5, dh6-6, Dmin-6, f-2-3, L-45, L1-30, tmax-1-8,	approx. 4 working days	5.3	1.5	6	6	2.3	45	30	1.8		To order
R.006.0100-10 AL41Fright, cm-3, a-5-3, b (+0.05)-1, dh6-6, Dmin-6, f-2-3, L-25, L1-10, tmax-1-8,	approx. 4 working days	5.3	1	6	6	2.3	25	10	1.8		To order
R.006.0100-10 CN45Fright, cm-2, a-5-3, b (+0.05)-1, dh6-6, Dmin-6, f-2-3, L-25, L1-10, tmax-1-8,	3 pieces	5.3	1	6	6	2.3	25	10	1.8		To order
R.006.0100-15 CN45Fright, cm-2, a-5-3, b (+0.05)-1, dh6-6, Dmin-6, f-2-3, L-30, L1-15, tmax-1-8,	approx. 4 working days	5.3	1	6	6	2.3	30	15	1.8		To order
R.006.0100-22 AL41F, cm-1, a-5-3, b (+0.05)-1, dh6-6, Dmin-6, f-2-3, L-37, L1-22, tmax-1-8,	approx. 4 working days	5.3	1	6	6	2.3	37	22	1.8		To order
R.006.0100-22 CN45Fright, cm-2, a-5-3, b (+0.05)-1, dh6-6, Dmin-6, f-2-3, L-37, L1-22, tmax-1-8,	6 pieces	5.3	1	6	6	2.3	37	22	1.8		To order
R.006.0100-25 AL41F, cm-1, a-5-3, b (+0.05)-1, dh6-6, Dmin-6, f-2-3, L-40, L1-25, tmax-1-8,	about 2 weeks	5.3	1	6	6	2.3	40	25	1.8		To order
R.006.0100-25 CN45Fright, cm-2, a-5-3, b (+0.05)-1, dh6-6, Dmin-6, f-2-3, L-40, L1-25, tmax-1-8,	approx. 4 working days	5.3	1	6	6	2.3	40	25	1.8		To order
R.006.0100-30 AL41F, cm-1, a-5-3, b (+0.05)-1, dh6-6, Dmin-6, f-2-3, L-45, L1-30, tmax-1-8,	about 2 weeks	5.3	1	6	6	2.3	45	30	1.8		To order
R.006.0100-30 CN45Fright, cm-2, a-5-3, b (+0.05)-1, dh6-6, Dmin-6, f-2-3, L-45, L1-30, tmax-1-8,	approx. 4 working days	5.3	1	6	6	2.3	45	30	1.8		To order
R.006.0100-35 AL41F, cm-1, a-5-3, b (+0.05)-1, dh6-6, Dmin-6, f-2-3, L-50, L1-35, tmax-1-8,	about 2 weeks	5.3	1	6	6	2.3	50	35	1.8		To order
R.006.0100-35 CN45Fright, cm-2, a-5-3, b (+0.05)-1, dh6-6, Dmin-6, f-2-3, L-50, L1-35, tmax-1-8,	approx. 4 working days	5.3	1	6	6	2.3	50	35	1.8		To order
R.006.0100-35 K10Fright, cm-1, a-5-3, b (+0.05)-1, dh6-6, Dmin-6, f-2-3, L-50, L1-35, tmax-1-8,	approx. 2 working days	5.3	1	6	6	2.3	50	35	1.8		To order
R.006.0100-42 CN45Fright, cm-2, a-5-3, b (+0.05)-1, dh6-6, Dmin-6, f-2-3, L-57, L1-42, tmax-1-8,	approx. 4 working days	5.3	1	6	6	2.3	57	42	1.8		To order
R.006.0150-10 AL41Fright, cm-3, a-5-3, b (+0.05)-1-5, dh6-6, Dmin-6, f-2-3, L-25, L1-10, tmax-1-8,	approx. 4 working days	5.3	1.5	6	6	2.3	25	10	1.8		To order
R.006.0150-10 CN45Fright, cm-2, a-5-3, b (+0.05)-1-5, dh6-6, Dmin-6, f-2-3, L-25, L1-10, tmax-1-8,	approx. 4 working days	5.3	1.5	6	6	2.3	25	10	1.8		To order
R.006.0150-15 AL41F, cm-1, a-5-3, b (+0.05)-1-5, dh6-6, Dmin-6, f-2-3, L-30, L1-15, tmax-1-8,	approx. 4 working days	5.3	1.5	6	6	2.3	30	15	1.8		To order
R.006.0150-15 CN45Fright, cm-2, a-5-3, b (+0.05)-1-5, dh6-6, Dmin-6, f-2-3, L-30, L1-15, tmax-1-8,	2 pieces	5.3	1.5	6	6	2.3	30	15	1.8		To order
R.006.0150-22 AL41F, cm-1, a-5-3, b (+0.05)-1-5, dh6-6, Dmin-6, f-2-3, L-37, L1-22, tmax-1-8,	approx. 4 working days	5.3	1.5	6	6	2.3	37	22	1.8		To order
R.006.0150-22 CN45Fright, cm-2, a-5-3, b (+0.05)-1-5, dh6-6, Dmin-6, f-2-3, L-37, L1-22, tmax-1-8,	2 pieces	5.3	1.5	6	6	2.3	37	22	1.8		To order
R.006.0150-25 CN45Fright, cm-2, a-5-3, b (+0.05)-1-5, dh6-6, Dmin-6, f-2-3, L-40, L1-25, tmax-1-8,	approx. 4 working days	5.3	1.5	6	6	2.3	40	25	1.8		To order
R.006.0150-30 AL41F, cm-1, a-5-3, b (+0.05)-1-5, dh6-6, Dmin-6, f-2-3, L-45, L1-30, tmax-1-8,	approx. 4 working days	5.3	1.5	6	6	2.3	45	30	1.8		To order
R.006.0150-30 CN45Fright, cm-2, a-5-3, b (+0.05)-1-5, dh6-6, Dmin-6, f-2-3, L-45, L1-30, tmax-1-8,	approx. 4 working days	5.3	1.5	6	6	2.3	45	30	1.8		To order
R.006.0150-35 AL41F, cm-1, a-5-3, b (+0.05)-1-5, dh6-6, Dmin-6, f-2-3, L-50, L1-35, tmax-1-8,	approx. 4 working days	5.3	1.5	6	6	2.3	50	35	1.8		To order
R.006.0150-35 CN45Fright, cm-2, a-5-3, b (+0.05)-1-5, dh6-6, Dmin-6, f-2-3, L-50, L1-35, tmax-1-8,	approx. 4 working days	5.3	1.5	6	6	2.3	50	35	1.8		To order
R.006.0150-35 K10Fright, cm-1, a-5-3, b (+0.05)-1-5, dh6-6, Dmin-6, f-2-3, L-50, L1-35, tmax-1-8,	approx. 4 working days	5.3	1.5	6	6	2.3	50	35	1.8		To order
R.006.0200-10 AL41F, cm-1, a-5-3, b (+0.05)-2, dh6-6, Dmin-6, f-2-3, L-25, L1-10, tmax-1-8,	approx. 4 working days	5.3	2	6	6	2.3	25	10	1.8		To order
R.006.0200-10 CN45Fright, cm-2, a-5-3, b (+0.05)-2, dh6-6, Dmin-6, f-2-3, L-25, L1-10, tmax-1-8,	approx. 4 working days	5.3	2	6	6	2.3	25	10	1.8		To order
R.006.0200-15 AL41Fright, cm-3, a-5-3, b (+0.05)-2, dh6-6, Dmin-6, f-2-3, L-30, L1-15, tmax-1-8,	approx. 4 working days	5.3	2	6	6	2.3	30	15	1.8		To order
R.006.0200-15 CN45Fright, cm-2, a-5-3, b (+0.05)-2, dh6-6, Dmin-6, f-2-3, L-30, L1-15, tmax-1-8,	approx. 4 working days	5.3	2	6	6	2.3	30	15	1.8		To order
R.006.0200-22 AL41F, cm-1, a-5-3, b (+0.05)-2, dh6-6, Dmin-6, f-2-3, L-37, L1-22, tmax-1-8,	approx. 4 working days	5.3	2	6	6	2.3	37	22	1.8		To order
R.006.0200-22 CN45Fright, cm-2, a-5-3, b (+0.05)-2, dh6-6, Dmin-6, f-2-3, L-37, L1-22, tmax-1-8,	approx. 4 working days	5.3	2	6	6	2.3	37	22	1.8		To order
R.006.0200-25 AL41F, cm-1, a-5-3, b (+0.05)-2, dh6-6, Dmin-6, f-2-3, L-40, L1-25, tmax-1-8,	approx. 4 working days	5.3	2	6	6	2.3	40	25	1.8		To order
R.006.0200-25 CN45Fright, cm-2, a-5-3, b (+0.05)-2, dh6-6, Dmin-6, f-2-3, L-40, L1-25, tmax-1-8,	approx. 4 working days	5.3	2	6	6	2.3	40	25	1.8		To order
R.006.0200-25 K10Fright, cm-1, a-5-3, b (+0.05)-2, dh6-6, Dmin-6, f-2-3, L-40, L1-25, tmax-1-8,	approx. 4 working days	5.3	2	6	6	2.3	40	25	1.8		To order
R.006.0200-30 AL41F, cm-1, a-5-3, b (+0.05)-2, dh6-6, Dmin-6, f-2-3, L-45, L1-30, tmax-1-8,	approx. 4 working days	5.3	2	6	6	2.3	45	30	1.8		To order
R.006.0200-30 CN45Fright, cm-2, a-5-3, b (+0.05)-2, dh6-6, Dmin-6, f-2-3, L-45, L1-30, tmax-1-8,	approx. 4 working days	5.3	2	6	6	2.3	45	30	1.8		To order
